NETBOX Profilebox

NETBOX Profilebox

NETBOX Profilebox is a standard power, data and multimedia unit in aluminium finish.

Product Specification

  • Durable and sturdy aluminium profile
  • Individual configuration
  • Customizable up to 35 outlet modules
  • Separate power circuits possible
  • Optional: Male and female connectors in same end cap
  • Plug & Play technology

Application Range

  • Workstations
  • Cable Trays
  • Home Offices
  • Meeting Tables

Technical Details

  • Rated for 110 to 250V, and up to a maximum of 20A
  • Material: ABS-FR; low concentration of heavy metal
  • Power and data are isolated to eliminate interferences
  • Provision for static current discharge
  • Available in various lengths
  • Tool-free installation
  • Wiring: 3 x 1.5mm2 standard; 3 x 2.5mm2 upon request

Colors

Related Products

NETBOX Leaf

The NETBOX Leaf is a surface-mounted unit designed to optimize space and adapt to desk-sharing environments thanks to its compact footprint and elegant form.
Easy to install and use, it can be securely mounted using Powerstrips or a table clamp, offering durable and efficient access to power and communication outlets.
This unit can be configured with 250 module options and comes hardwired with a built-in starter or connector cable of customizable length.
Inspired by modern organic aesthetics, the NETBOX Leaf features fluid lines and dynamic curves with end-caps shaped like a leaf.

Product Specification

  • Highly flexible and easy to relocate
  • Powerstrips allow unit to be installed anywhere on table-top surface
  • Optional: Installation with mounting clamp
  • Customizable into various length and configurations
  • Direct access to power and data modules
  • Comes with built-in starter or connector cable in varying length
  • Plug & Play technology

Application Range

  • Desks
  • Hotels
  • Workstations
  • Universities
  • Training tables
  • Home Offices

Technical Details

  • Rated for 110V to 250V and a maximum of 20A according to country specific standards
  • Material: ABS and PA6 in V0 specification (self-extinguishing according to UL94)
  • Low concentration of heavy metal
  • Aluminium casing is safely grounded to avoid electrocution
  • Available in various lengths
  • Tool-free installation
  • Wiring: 3 x 1.5mm2 standard; 3 x 2.5mm2 upon request

NETBOX Smart

NETBOX Smart is a detachable desktop mounted power & data unit in aluminium finish.

Product Specification

  • Highly flexible and easy to relocate
  • Power strips allow unit to be installed anywhere on table-top surface
  • Optional: Installation with mounting clamp
  • Customizable into various configurations
  • Direct access to power and data modules
  • Available in various lengths
  • Tool-free installation
  • Comes with built-in starter or connector cable in varying length
  • Plug & Play technology

Application Range

  • Executive Desks
  • Workstations
  • Training tables
  • Hotel Rooms
  • Home Offices

Colours

  • Silver/White
  • Silver/Black
  • Champagne/White
  • Champagne/Black

Technical Details

  • Rated for 110V to 250V and a maximum of 20A according to country specific standards
  • Material: ABS and PA6 in V0 specification (self-extinguishing according to UL94)
  • Low concentration of heavy metal
  • Aluminium casing is safely grounded to avoid electrocution
  • Wiring: 3 x 1.5mm2 standard; 3 x 2.5mm2 upon request

Davis Bus Track System

Applications

  • High-rise buildings
  • Commercial complexes
  • Industrial plants

Characteristics

  • Carefully designed power busways to handle all electrical, thermal, and mechanical load requirements
  • Robust enclosures to ensure optimum heat dissipation
  • Advanced manufacturing with computerised CNC machines for improved precision and accuracy
  • Special epoxy insulation for greater fire resistance
  • Fully mechanical interlocks to prevent tampering and improve safety

TECHNICAL DETAILS

  • Manufactured and tested for compliance with the latest international standards
  • Designed to withstand voltages up to 11kV at frequencies of 60Hz and higher
  • Certified with KEMA/DEKRA and ASTA for protection against short circuits

Revos

Revos are heavy duty connectors and are specifically designed for use in tough environment conditions. The main areas of use are in automotive industry, packaging machinery and equipment, instrumentation, control, and automation equipment.

Their housing protects against mechanical impact and prevent entry of spray water and dust. The system’s sub-assemblies undergo a quality check in-house, which simplifies installation and saves time at the end location.

NETBOX Profilebox Sub

NETBOX Profilebox Sub is a compact; power, data and multimedia unit. Built in durable aluminium finish, the unit is designed for easy under mounting, ideally suited for your workstation, meeting table and home office.

Product Specification

  • Durable and sturdy aluminium profile
  • Individual configuration
  • Customizable up to 35 outlet modules
  • Separate power circuits possible
  • Plug & Play technology

Application Range

  • Workstations
  • Cable Trays
  • Home Offices
  • Meeting Tables

Technical Details

  • Rated for 110 to 250V, and up to a maximum of 20A
  • Material: ABS-FR; low concentration of heavy metal
  • Power and data are isolated to eliminate interferences
  • Provision for static current discharge
  • Available in various lengths
  • Tool-free installation
  • Wiring: 3 x 1.5mm2 standard; 3 x 2.5mm2 upon request

Netbox Axial

NETBOX Axial is a built-in solution that closes flat and flush against its mounted surface. It opens from the front to reveal power, voice, and data sockets whenever required.
The rubber lip allows cables to move to and from devices such as computers, telephones, and multimedia equipment, while the unit remains closed even when in use.

Product Specification

  • Unit opens at 60° angle
  • Manual lift–up cover for easy access”
  • Cable outlet with rubber lips
  • Unit sits flush with mounted surface
  • Available in any length
  • Customizable into various configurations
  • Tool free installation
  • Quick installation with the click-stop mechanism
  • Plug & Play technology

Application Range

  • Executive Desks
  • Workstations
  • Conference Tables
  • Boardroom Tables
  • Meeting Tables

Technical Details

  • Rated for 110V to 250V and a maximum of 20A according to country specific standards
  • Low concentration of heavy metal
  • Material: PA6-FR
  • Wiring: 3 x 1.5mm2 standard; 3 x 2.5mm2 upon request
